Button Spelter Socket
(Fast connector sockets with pin, Quick socket)
Finish
All Fast Connector Sockets are finished with a hot dip galvanized fin.
Application
Connect with wire rope by wirelock or Zinc-base, casting the core. Easy to load and unload. Help customers reduce replacement time and labor cost. Quick released construction.
| Code | Wire Rope Dia (mm) | Dimensions (mm) | |||||||||||
| mm | inch | A | B | C | D | E | F | G | H | I | J | K | |
| GROBSC01 | 15-16 | 5/8 | 100 | 80 | 35 | 60 | 36 | 60 | 30 | 55 | 32 | 18 | 112 |
| GROBSC02 | 17-19 | 11/16~3/4 | 110 | 90 | 43 | 75 | 38 | 72 | 35 | 65 | 38 | 21 | 129 |
| GROBSC03 | 20-22 | 13/16~7/8 | 120 | 110 | 47 | 85 | 44 | 82 | 40 | 77 | 44 | 24 | 147 |
| GROBSC04 | 23-26 | 7/8~1 | 135 | 130 | 63 | 104 | 51 | 95 | 50 | 85 | 50 | 28 | 161 |
| GROBSC05 | 28 | 1 1/8 | 150 | 160 | 68 | 120 | 57 | 107 | 55 | 110 | 56 | 32 | 188 |
| GROBSC06 | 30-32 | 1 1/4 | 165 | 170 | 75 | 130 | 72 | 119 | 63 | 117 | 62 | 36 | 210 |
| GROBSC07 | 34-36 | 1 3/8 | 175 | 180 | 80 | 140 | 77 | 125 | 67 | 135 | 70 | 39 | 220 |
| GROBSC08 | 38-40 | 1 1/2 | 190 | 190 | 85 | 150 | 82 | 150 | 70 | 145 | 75 | 42 | 230 |
| GROBSC09 | 42 | 1 5/8 | 210 | 210 | 90 | 156 | 86 | 140 | 75 | 150 | 80 | 45 | 240 |
| GROBSC10 | 46 | 1 7/8 | 260 | 220 | 90 | 160 | 90 | 160 | 80 | 160 | 88 | 52 | 226 |
